HLG Scorpion Diablo is designed for grows with low ceiling heights or for vertical racks. HLG Scorpion Diablo uses 6x QB648 Diablo Quantum Boards for an even light spread at just 12" from the canopy. This is a very efficient full spectrum horticulture lamp with an efficiency of 2.9 PPF/W
HLG Scorpion Diablo Manual
TOP FEATURES
Designed for low ceiling heights or vertical racks
Highest efficiency full spectrum grow lamp
Full Spectrum White and 660nm Red
Reliable passive-cooled design
Better canopy light penetration with diffused light
Dimmable power supply included
Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
3 Year warranty
SPECIFICATIONS
Power 60-650 Watts
Voltage Range 100-277 VAC 50-60Hz
LED Samsung LM301H & Deep Red
Flowering Footprint 5' x 5' at 18"
Veg Footprint 6' x 6' at 24
System PPF Efficacy 2.9 ≈mol/joule
Total output 1900 PPF
Dimensions 38.5" x 36" x 2.75"
Recommended Mounting Height 12-18 inches above canopy
The PHOTOBIO MX changes everything. We took a step back, evaluated all the fixtures on the market, and then set out to do things entirely different. The result is a 680W fixture delivering 15% more light to your canopy, using 35% less power than a 1000W DE fixture. Increase yields while driving down operational cost. The spectrums were developed in a private research laboratory to drive flower yield and elicit market desirable traits in short day resin producing crops.PHOTOBIO MX abandons the bar style concept in favor of a more efficient contiguous circuit board to deliver unparalleled PPFD uniformity to the canopy. Extensive thermal modeling and testing was conducted to ensure diodes remain well below operating temperature to maintain consistent light output and yields. 0-10V PHOTO LOC Light Output Control allows you to precisely regulate the amount of light delivered to your plant canopy when paired with the available Autopilot PX Series controller.The iLOC Integrated Light Output Control on board dimming knob allows the grower to adjust the photon output intensity to accommodate the various stages of plant growth for optimal photosynthesis activation. With the knob adjusted to 100% using 240V, the MX uses 664W and puts out 1700 mol/s photon flux (PPF). With the knob adjusted to 40%, the MX uses 270W and puts out 40% of the photon flux. The high efficiency S4 spectrum does not change when using the dimmer knob and still provides ideal red to blue ratio for vigorous growth and maximized flower development.PHOTOBIO MX's design is multilayer rack centric, providing the ability to double or triple your canopy square footage within your existing structures footprint. The driver is mounted below the fixture to maximize vertical grow space and has the ability to be remotely mounted.PHOTOBIO MX is designed for the serious horticultural professional looking to increase business sustainability by reducing power consumption while simultaneously improving crop performance and yield. The PHOTOBIO MX is also a qualified product listed with DLC, which makes the fixture eligible for energy rebates for futher cost savings while also saving significant energy while optimizing plant growth and health.FEATURES:1768 umol/s Photon Flux @ 277V2.6 µmol/J Efficacy @ 277ViLOC Integrated Light Output Control allows manual adjustment of light outputSettings are 40%-55%-70%-85%-100%-PX ControlDriver can be mounted remoteRobust commercial design keeps LED's running coolPrecisely control photon output when paired with Autopilot PX series controller (PX2 and above)Slim design maximizes vertical growing space with remote capable driver100-277V Driver rangeIP65 wet location rated protection against water and dustIncludes PHOTO LOC signal cableIncludes a voltage specific power cable chosen by the customerDLC listed (H-RR6RGRH) and qualifies for utility rebates, which play a significant role in optimizing the cost effectiveness of a lighting project
Specifications:
Light Source: LED
Veg Coverage: 5' x 5'
Bloom Coverage: 4' x 4'
Light Output PPF: 1890 µmol/s
Efficacy PPE: 2.7 µmol/J
AC Input Power: 700W
AC Input Voltage: 120-277V AC, 50/60Hz
Light Distribution: 120°
Mounting Height: 12" - 24" (30.48cm - 60.96cm)
Thermal Management: Passive
Max Ambient Temperature: 95°F / 35°C
Dimming: 0-10V
Total Harmonic Distortion (THD): 15%
Lifetime: L90 > 50,000hrs
Certifications: DLC, UL 8800, UL 1598
Warranty: 5 Year Standard Warranty
Product Features:
No Tools Required for Assembly
Self-Assembly in Under 5 Minutes
8-Bar Design for Optimal Light Distribution
Daisy Chain Capable
Designed for Maximum Plant Health and Yield
Lightweight and Easy to Install
The PHOTOBIO•MX2 changes everything, again. The best-selling PHOTOBIO MX fixture evolves with higher output and better efficiencies while still delivering the same great recipe many growers have come to love. We care about you and your crops. We know nothing will stop you from focusing on the goal and trying to do better. Photobio has similar beliefs, to always try to raise the bar and be BETTER. The result is a 1,870 uMol/s (PAR) fixture that consumes the same power as the original MX while delivering enhanced efficacy at 2.8 uMol/J. The PHOTOBIO MX2 offers 10% more photon output, 10% better efficiency and a 47% weight reduction compared to the original model. The wide light bars deliver the uniformity and intensity that professional growers desire. Increase yields while driving down operational cost with the PHOTOBIO MX2.
MX2 Upgrades Comparing to Previous Generation:
10% more light output
10% increase in fixture efficacy
47% weight reduction
Improved locking hinges for easy installation and longevity
Everything you loved about PHOTOBIO MX is inherited to MX2:
Best-in-class proprietary optical encapsulation process for the LED coating.
S4 Spectrum: Full spectrum optimized for all stages of growth and friendly to workers.
iLOC on-board dimming: Stay in control without an external controller.
Standard 0-10v dimming: compatible with all PHOTOBIO dimming interfaces and major controllers.
ETL Listed and DLC Hort QPL Listed: eligible for energy rebates
Heavy duty and premium quality: Efficient architecture-grade aluminum heatsink, powder coated finish
IP65 Rating for dust and water protection
5-year Warranty backed by the Hydrofarm team.
FEATURES:
1,906 µmol/s Photon Flux (PBAR 280-800 nm)
1,870 µmol/s Photon Flux (PAR 400-700 nm)
2.8 µmol/J Efficacy @ 277V
680W Rated Input Power
Auto adjusting 100-277V driver input range
iLOC Integrated Light Output Control allows manual adjustment of light output
Dim Settings are 40%-55%-70%-85%-100%-PX Control
Precisely control photon output when paired with Autopilot PX series controller (PX2 and above)
Slim design maximizes vertical growing space
Robust commercial design keeps LED's running cool
Includes PHOTO•LOC DC signal cable
Fully compatible with optional PHOTOBIO AC Power Distribution Tree cabling system - enables interconnection of multiple fixtures on a single power drop - reducing electrical infrastructure costs*
Fully compatible with optional PHOTOBIO DC Communications Tree cabling system - enables interconnection of multiple fixtures on a centralized controller
HLG Scorpion R Spec is designed for grows with low ceiling heights or for vertical racks. HLG Scorpion R Spec uses 6x Boards for an even light spread at just 12" from the canopy. QB288 uses Samsung's latest LM301H and Deep Red LED 660nm. This unit is dimmable, with wattage output from 60 to 600 watts.
Fluence’s SPYDR FANG is a high-performance top-lighting solution for the craft cannabis grower or home hobbyist. Enabling growers to command their grow with an efficiency optimized output (PPF), PhysioSpec™ R4 indoor spectrum, and included 0-100% dimmer for easy control and full-cycle cultivation.
Light Output: PPF 1600 µmol/s
Efficacy: 2.6 µmol/J @ 240 V AC
AC Input Power: 626 W @ 240 V AC
AC Input Voltage: 120-277 V AC, 50/60 Hz
Light Distribution: 120°
Mounting Height Above Canopy 6” - 12” [15-30 cm]
Thermal Management: Passive
Dimming: Dimmer Module Included
Lifetime (Driver and LED Q90): >36,000 hrs
IP Rating per IEC60598-1: IP66
Certifications: UL 8800, UL 1598, CE, IEC60598-1
Warranty: 3 Year Limited Warranty
AC Cord, 6', NEMA 6-15P 240V included
HLG 650R Commercial Indoor Horticulture LED grow light is designed to replace a double-ended 1000 watt HID lamp. 650 R uses 4 of our custom designed full spectrum high efficiency white light quantum boards with Samsung LM301H and Deep Red LED 660nm . This unit is dimmable, with wattage output from 60 to 630 watts.
Features Samsung LM301H EVO LEDs each rated at 3.14 µmol/J PPE, the highest efficiency of LM301B, LM301H, and Bridgelux 3030 chips.
Programmed with schedule controls, sunrise/sunset dimming, and 10 brightness levels; UIS™ platform-compatible for WiFi app control.
Bar-style fixture with algorithmically spaced diodes optimized for even coverage, deep canopy penetration, and hotspot reduction.
Passive cooling LED driver is removable to balance heat dissipation; also supports daisy-chaining with up to 80 grow lights.
6 x 6 ft. Veg. Coverage | 5 x 5 ft. Flower Coverage | Samsung LM301H EVO Chips | 2688 Diodes | 730W | 2013 PPFD | ETL Cert. 5021417
PHOTOBIO•TX high efficiency LED top light is designed for greenhouse and indoor applications. The slim design minimizes sun interference while providing greater access to the plant canopy. The ultra-effective commercial design utilizes a closed loop heat pipe cooling system to rapidly wick heat from diodes, providing superior heat dissipation and longevity. The high efficiency S4 spectrum provides ideal conditions for both human and plant health to deliver better working conditions and consistent crop quality. This fixture allows horticulture professionals increased performance and yields while maximizing ROI.
Features Samsung LM301H EVO LEDs each rated at 3.14 µmol/J PPE, the highest efficiency of LM301B, LM301H, and Bridgelux 3030 chips.
Programmed with schedule controls, sunrise/sunset dimming, and 10 brightness levels; UIS™ platform-compatible for WiFi app control.
Bar-style fixture with algorithmically spaced diodes optimized for even coverage, deep canopy penetration, and hotspot reduction.
Passive cooling LED driver is removable to balance heat dissipation; also supports daisy-chaining with up to 80 grow lights.
5 x 5 ft. Veg. Coverage | 4 x 4 ft. Flower Coverage | Samsung LM301H EVO Chips | 1074 Diodes | 500W | 1991 PPFD | ETL Cert. 5021417
PRODUCT DESCRIPTION
An indoor plant grow light designed for grow tents and large grow spaces to improve your plant's growth rate and its yields. Utilizes Samsung LM301H EVO diodes that are algorithmically spaced on a bar-style form factor to evenly distribute lighting coverage while diminishing hotspots. Its modular design enables you to remove the driver to remotely mount it away from this fixture and balance heat dissipation. This heat dissipation is supported by its steel and aluminum build, which enables magnetic mounting and is IP-65-rated to withstand humid environments. This grow light meets ETL standards (certificate #5021417) for electrical appliance safety, ensuring secure use in lighting applications. The included smart controller features schedule programming and daisy-chain support to connect more bar LED grow lights in a linear arrangement by using splitter dongles (sold separately). This product is a part of the UIS™ platform of grow devices and smart controllers, designed to integrate with each other to achieve your ideal environment.
INDUSTRY-LEADING LED CHIPS
Each IONFRAME light features genuine Samsung LM301H EVO diodes, the latest in horticulture lighting technology that emits intense brightness at greater efficiency. This performance is superior to leading Samsung LM301H and LM301B LEDs, as well as Bridgelux 3030, and other previous-generation LEDs. EVO diodes help improve plant growth by emitting greater light quality and more light output per diode, with a higher blue spectrum and greater efficiency when compared to non-EVO diodes. The IONFRAME EVO is supported by an array of (6) 395 nm UV diodes, (54) 660 nm and (6) 730 nm OSRAM red diodes to complete its full spectrum light output.
SCHEDULE AND BRIGHTNESS CONTROLS
The included schedule controller can automatically adjust light based on the time of day. It features 10 light intensity levels and a scheduling mode that will cyclically activate this grow light. Customize this daily cycling with an innovative sunrise and sunset setting that gradually brightens and dims the lighting to accurately replicate the sun's movement. Use this grow light with an advance UIS controller like CONTROLLER 69 PRO to fully automate it by integrating it into the UIS platform. This will enable further access to remote control over WiFi and advance programming like automation and grow recipes when connecting to the AC Infinity app.
The Fluence SPYDR 2r LED Grow Light is an advanced lighting solution designed specifically for craft herb cultivators. It offers a powerful 1600 µmol/s PPF output, ideal for micro-growers aiming to optimize their harvest. Equipped with the PhysioSpec™ Broad R4 spectrum, the SPYDR 2r ensures balanced, full-cycle cultivation, while the included 0-100% dimmer provides precise control over light intensity throughout the growth stages. This high performance grow light is tailored for those seeking to command their indoor growing environment with efficiency and ease. AC Cord and DC Extension Cable sold separately.
Product Code: 9124 017 02470
Product SpecificationsLight Source: LEDSpectrum: PhysioSpec™ Broad R4Light Output: PPF 1600 µmol/sEfficacy: 2.6 µmol/J @ 240 V ACAC Input Power: 626 W @ 240 V ACAC Input Voltage: 120-277 V AC, 50/60 HzLight Distribution: 120°Mounting Height Above Canopy: 6in - 12inThermal Management: PassiveMax. Ambient Temperature/Humidity: 95°F, 90% RHDimming: M12 Connectors, 0-10v Signal, Dim to offTotal Harmonic Distortion (THD): <10% at 100% outputLifetime (Driver and LED Q90): > 36,000 hrs.IP Rating IEC60598-1: IP66Certifications: UL 8800, UL 1598, CE, IEC60598-1Warranty: 5 Year WarrantyDLC Reported Application: Indoor (Stacked and Non-stacked)Position/Use Case: Top light/Sole-sourceDimensions: 47in x 43in x 1.26in (Unit), 14.56in x 5.26in x 2.62in (Power Supply)Weight: 16.7lb (Light Bar), 8.1lb (Power Supply)
Full 4x4 and 5x5 coverage, and the range most single-tent flowering rooms land in. Check your ceiling height and your ventilation before you go up a tier.
